Crimping die for uninsulated tube and crimp cable lugs to DIN 46237, 0.75 to 2.5 mm² - Knipex 97 49 10

Uninsulated tube and crimp cable lugs to DIN 46237 require a standardised crimp contour so that the joint keeps conducting. This crimping die brings the nests for 0.75, 1.5 and 2.5 mm² and also handles the uninsulated butt and crimp connectors to DIN 46341.

Benefits

• For uninsulated tube and crimp cable lugs to DIN 46237 with nests for 0.75, 1.5 and 2.5 mm².
• Also for uninsulated butt and crimp connectors to DIN 46341, so one die covers both designs.
• Interchangeable die for the manual and electromechanical KNIPEX crimping system pliers of the 97 43 xx series, so one tool covers many connector types.
• Precision die for a consistent crimp quality over the whole service life.
• Compact die of 12 x 32 mm and 37 g, it adds hardly any load to the tool set.

Technical data

Areas of use

Electrical installation, switchgear and control cabinet building, machine and vehicle construction. The die belongs wherever standardised uninsulated cable lugs and butt connectors are fitted to stranded wire.

Standards and conformity

The manufacturer names the connector standards DIN 46237 for tube and crimp cable lugs and DIN 46341 for butt and crimp connectors. He states no separate tool standard for this product. According to the manufacturer the die contains no substances of very high concern under REACH and the RoHS directive does not apply.
