Four-mandrel crimping pliers for turned contacts 0.14 to 6 mm², digital setting, length 240 mm - Knipex 97 52 65 DG

Turned contacts in connectors from Harting, Phoenix Contact or TE Connectivity have to be crimped to a hundredth of a millimetre. The 97 52 65 DG four-mandrel crimping pliers feed the crimping mandrels in increments of 0.01 mm and show the value digitally, the range covers 0.14 to 6 mm².

Benefits

• Crimp mandrel feed adjustable in increments of 0.01 mm and digitally readable, in mm, inches or comparable selector positions to MIL standard.
• Patented electronic wear monitoring with warning function, so the replacement point is not missed.
• Four synchronously fed crimping mandrels give an even crimp all round the contact.
• Trigger lock to IEC 60352 as a positive lock that can be released ensures consistent crimp quality.
• Recalibration function with the enclosed test pin, the basic setting can be checked at any time.
• Mounted contact holder for turned pin and socket contacts, exchangeable for holders of other contact manufacturers.

Technical data

Areas of use

Connector assembly in machine and plant engineering, control cabinet building and test departments. Wherever turned pin and socket contacts in rectangular and circular connectors have to be crimped evenly and in a documented way.

Standards and conformity

The trigger lock complies with IEC 60352 for crimped connections. According to the manufacturer the pliers contain substances of very high concern under the REACH regulation, the requirements of the RoHS directive are met.
