Four-mandrel crimping pliers for turned contacts, basic pliers without locator, 0.14 to 6 mm² - Knipex 97 52 65 A

Turned contacts from Harting, Ilme, Phoenix, Amphenol, Walther, HTS, Contact or Weidmüller each call for their own crimping dimension. The four-mandrel crimping pliers 97 52 65 A cover the range from 0.14 to 6 mm² and let the mandrel feed be set to the individual contact with an adjusting wheel in steps of 0.01 mm. A table for calculating the settings is included.

Advantages

• Basic pliers without locator, suitable for turned pin and socket contacts from various contact manufacturers.
• Fine adjustment of the pressure to different conductor cross-sections by adjusting wheel, in steps of 0.01 mm.
• Reliable crimping thanks to the synchronised feed of the four mandrels, the contact is compressed evenly.
• Process-secure and consistently high crimp quality thanks to the IEC 60352 compliant trigger lock, which can be unlocked.
• Checking of the basic setting with the enclosed test gauge, plus a table for calculating the settings.
• Separately available locators enable exact positioning of the crimp contacts, for contact diameters up to 7.5 mm.

Technical data

Areas of use

Assembly of rectangular and circular connectors in machine building, automation, rail technology and plant construction. Wherever turned contacts from different manufacturers have to be crimped repeatably with a single tool.

Standards and conformity

The trigger lock complies with IEC 60352 for solderless connections. According to the manufacturer the pliers contain substances of very high concern under REACH, the requirements of the RoHS directive are met.
