Soldering tip SxV Series chisel 2,4 x 18,3 mm, 460 °C - Oki SCV-CH24A

The chisel soldering tip SCV-CH24A from the Oki SxV Series transfers heat through the self regulating SmartHeat technology directly at the contact point and runs at a fixed tip temperature of 460 °C. With 2,4 mm width and 18,3 mm length it fits the handpieces of the Oki PS and MFR soldering systems.

Benefits

• suited to ceramics and applications with high thermal demands
• long version
• optimised for thermal performance
• fits the handpieces of the PS and MFR systems

Technical data

Applications

Hand and rework soldering on printed circuit boards, THT and SMT joints as well as temperature or mass sensitive components, depending on the selected tip temperature.

Compatibility & scope of delivery

Fits the handpieces of the Oki PS-900 and MFR soldering systems. The PS-CA3 heating element accepts SxV and CsV tips. Scope of delivery: 1 soldering tip.

SmartHeat self regulating technology, lead-free capable, ESD-safe. Origin USA.
