Solder fume extraction unit T15 high vacuum for up to 15 extraction points 230 V - Donaldson Bofa 30766581-1454

When several hand soldering benches need extraction at the same time but there is no room for an individual unit on every table, a high-vacuum central unit takes over. The Bofa T15 draws fume and deposits through hoses and small-bore attachments and filters them in three stages up to HEPA level.

Benefits

• High-vacuum principle extracting through hoses and small-bore attachments, capturing fume right at the joint
• Rated for up to 15 users or extraction points at a recommended 22 l/min per tip
• Three-stage filtration with F7 prefilter (85 percent at 0.8 µm) and HEPA filter at 99.997 percent, 0.3 µm
• Low noise level of 65 dBA, suitable for occupied production areas
• Powder-coated housing and CE certification, motor rating 0.4 kW at 230 V

Technical data

Applications

Centralised tip extraction on hand soldering lines, micro extraction at rework and repair benches and operation of vacuum pens when handling small components. Typical users are electronics manufacturers, service workshops and test and development laboratories.

Compatibility and scope of delivery

The T15 works with the Bofa soldering tip extraction sets such as the ESD tip kit A1090026 and with the ESD silicone hoses 4.5 x 6.5 mm and 6 x 8 mm. The matching wear part is the prefilter A1030095. Delivery comprises the extraction unit in 230 V version, hoses and extraction attachments are ordered separately to suit the workstation.
