Solder fume carries flux aerosols that must not reach the room air. The portable Zero Smog EL extraction unit moves up to 150 m³/h and filters through an M5 fine dust prefilter, a 2.4 m² HEPA H13 stage and activated carbon granulate. At 53 dBA and 335 x 360 x 445 mm it fits under or beside the workbench.
Solder fume extractor 150 m³/h HEPA H13 Zero Smog EL 230 V - Weller FT91010699N
WELLER
Original product
Net price (excl. VAT)
€838.73
Item
WL41646
Manufacturer no.
FT91010699N
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.FT91010699N
ConditionNew
Article
WL41646
Frequently Bought Together
-
This Item:
€838.73
-
Solder fume extraction unit MG 140 with clean room filter 140 m³/h for 2 workstations - Weller 145-1002-ESDN
€2,369.23
-
Extraction hose Easy-Click 60, diameter 60 mm, length 1 m - Weller 700-3040-ESD
€52.98
Total price
Flux aerosols from the soldering process have to be captured before they spread through the room. The portable Zero Smog EL extraction unit delivers up to 150 m³/h at 2500 Pa vacuum and uses a three-stage filter train of M5 prefilter, HEPA H13 and activated carbon granulate.
Benefits
- Volume flow up to 150 m³/h at a maximum vacuum of 2500 Pa
- 2.4 m² HEPA H13 filter area for long service intervals
- Separately replaceable M5 fine dust prefilter protects the main stage
- Activated carbon granulate filter for the gas phase
- Four speed settings to match the power to the capture point
- Electronic filter monitoring with filter alarm
- Long-life EC gas blower, 53 dBA in operation
Technical data
| Item number | WL41646 |
| Model | Zero Smog EL |
| Manufacturer | Weller |
| Manufacturer item number | FT91010699N |
| Dimensions (LxWxH) | 335 mm x 360 mm x 445 mm |
| Voltage | 230 V |
| Frequency | 50/60 Hz |
| Fuse | 1.25 A |
| Vacuum max. | 2500 Pa |
| Volume flow max. | 150 m³/h |
| Noise level | 53 dBA |
| Prefilter | fine dust M5 |
| Main filter | HEPA H13, 2.4 m² |
| Gas filter | activated carbon granulate |
| Type of vacuum generator | EC gas blower |
| Order unit | piece |
Applications
Point extraction at hand soldering, rework and repair benches in electronics manufacturing as well as at bonding and dispensing stations with low fume volumes.
Compatibility and scope of delivery
Delivery comprises the Zero Smog EL extraction unit for 230 V. Extraction arms, nozzles and replacement filters are ordered separately. The compact 335 x 360 x 445 mm housing allows placement under the bench.
| Manufacturer Nr. | FT91010699N |
|---|---|
| Manufacturer | Weller |
| Weight | 0.100000 |
| GPSR manufacturer information | WELLER Tools GmbH Carl-Benz-Strasse 2 DE-74354 Besigheim www.weller.eu |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
