Precision nippers for the finest cutting work in electronics and precision mechanics, 115 mm long at 70 g, with multi-component sleeves on the handles. Box joint and low-friction double leaf spring give a smooth and even opening action. The laser hardened edges from 56 HRC cut soft wire up to 2.0 mm dia. and hard wire up to 0.6 mm dia.
Electronics end cutting nippers with multi-component grips, edges from 56 HRC, 115 mm - Knipex 64 02 115
KNIPEX
Original product
Net price (excl. VAT)
€40.57
Item
WL61614
Manufacturer no.
64 02 115
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.64 02 115
EAN4003773035343
ConditionNew
Article
WL61614
Frequently Bought Together
-
This Item:
€40.57
-
ESD Case, black, 170 x 130 x 37 mm - Weller 504AE
€105.97
-
Lindström 7291. Diagonal end cutter, Supreme series, 11° angled, fine bevel, 0.35-1.25 mm
€70.04
Total price
Trimming component leads close to the board takes a tool that cuts cleanly and sits well in the hand. The 64 02 115 electronics end cutting nippers combine a box joint with multi-component sleeves on the handles, and their laser hardened edges from 56 HRC cut soft wire up to 2.0 mm dia.
Benefits
- Handles with multi-component sleeves for a secure hold during long production runs.
- Box joint keeps the cutting edges precisely aligned.
- Low-friction double leaf spring for a smooth and even opening action.
- Cutting edges additionally laser hardened, cutting edge hardness at least 56 HRC.
- Capacity from 2.0 mm dia. soft wire down to 0.6 mm dia. hard wire over a 16 mm cutting edge.
- Mirror polished head with a fine film of oil for rust protection, with no peeling chrome that could cause circuit faults.
Technical data
| EAN | 4003773035343 |
|---|---|
| Head | mirror polished |
| Handles | with multi-component sleeves |
| Weight | 70 g |
| Dimensions | 115 x 62 x 17 mm |
| Standard | DIN ISO 9654 |
| Cutting capacity soft wire (diameter) | 2.0 mm dia. |
| Cutting capacity medium hard wire (diameter) | 1.0 mm dia. |
| Cutting capacity hard wire (diameter) | 0.6 mm dia. |
| Head width (A) | 11 mm |
| Jaw length (B) | 6 mm |
| Jaw thickness at the joint (D) | 7.5 mm |
| Cutting edge length (C) | 16 mm |
| REACH conformity | contains no SVHC |
| RoHS conformity | not applicable |
Areas of use
Electronics manufacturing and repair, PCB assembly, precision mechanics, model making and laboratory work. For trimming component leads and thin wires flush.
Standards and conformity
The nippers comply with DIN ISO 9654 for electronics pliers. According to the manufacturer they contain no substances of very high concern under REACH. The RoHS directive does not apply to this product.
| Norm | DIN ISO 9654 |
|---|---|
| Manufacturer Nr. | 64 02 115 |
| Manufacturer | Knipex |
| EAN | 4003773035343 |
| Weight | 0.070000 |
| Height | 17 mm |
| Width | 62 mm |
| GPSR manufacturer information | KNIPEX-Werk Oberkamper Strasse 13 DE-42349 Wuppertal-Cronenberg www.knipex.de |
| Article authenticity | Original product |
| Condition of article | New |
| Overall length [mm] | 115.000000 |
