Compact bolt cutters CoBolt with opening spring and locking device, hard wire 4.0 mm dia., 200 mm - Knipex 71 32 200
Compact bolt cutters with a cutting recess whose opening spring and locking device are integrated into the slim multi-component sleeves. They cut bolts, nails and rivets up to 5.2 mm dia. and hard wire up to 4.0 mm dia., the edges are induction hardened to approx. 64 HRC. 200 mm long at 370 g.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
One-handed work on the ladder calls for a tool that opens by itself and stays safely closed in transport. On the CoBolt 71 32 200 the opening spring and the locking device sit in the handle sleeves, and it still cuts components up to 5.2 mm dia.
Benefits
- Opening spring and locking device integrated in the handle sleeves for comfortable work and safe transport.
- Recess in the blade for easier cutting of thicker wire.
- Precision cutting edges for soft and hard wire as well as piano wire, capacities up to 6 mm dia., 4.0 mm dia. and 3.6 mm dia.
- Cuts components such as bolts, nails and rivets up to 5.2 mm dia.
- Cutting edges additionally induction hardened, cutting edge hardness approx. 64 HRC.
- Gripping surface below the joint for gripping and pulling wires from 1.0 mm dia.
Areas of use
Metalworking, assembly and maintenance, fence and mesh work, electrical installation and strip-out jobs. Wherever bolts, nails, rivets, screws, springs and wire have to be cut and the tool still has to fit into the tool pouch.
Standards and conformity
According to the manufacturer the article contains substances of very high concern as defined by the REACH regulation. The RoHS directive does not apply to this product. The manufacturer states no further standards for this article.
Technical data
| EAN | 4003773066880 |
|---|---|
| Pliers | black atramentized |
| Handles | with slim multi-component sleeves |
| Weight | 370 g |
| Dimensions | 200 x 62 x 24 mm |
| REACH conformity | contains SVHC |
| RoHS conformity | not applicable |
| Cutting capacity soft wire (diameter) | max. 6 mm dia. |
| Cutting capacity medium hard wire (diameter) | 5.2 mm dia. |
| Cutting capacity hard wire (diameter) | 4.0 mm dia. |
| Cutting capacity piano wire (diameter) | 3.6 mm dia. |
| Manufacturer | Knipex |
| Manufacturer Nr. | 71 32 200 |
| GPSR manufacturer information | KNIPEX-Werk Oberkamper Strasse 13 DE-42349 Wuppertal-Cronenberg www.knipex.de |
| Condition of article | New |
| Article authenticity | Original product |
| Height | 24 mm |
| Width | 62 mm |
| Colour | Black |
| Farbe | schwarz |
| Overall length [mm] | 200 |
