Precision electronics diagonal cutter with bolted joint, 64 HRC cutting edges, 125 mm - Knipex 79 02 125 S1

Correcting cable harnesses and working on delicate electronic components calls for a cut that lands exactly where it should without damaging the insulation next to it. The 79 02 125 S1 precision electronics diagonal cutter has a round head with rounded edges all over and cutting edges of approx. 64 HRC that handle hard wire up to 0.7 mm dia.

Benefits

• Very precisely ground, sharp cutting edges with a very small bevel for exact cuts on delicate electronic components.
• Cutting edges additionally induction hardened to approx. 64 HRC, hard wire up to 0.7 mm dia.
• Round head with all edges rounded, which reduces the risk of damaging the insulation when correcting cable harnesses.
• Bolted joint with carefully manufactured joint surfaces for even, low friction movement throughout the entire opening range.
• Approx. 20% lighter than conventional electronics pliers, which tells over a long assembly shift.
• Smooth running double spring for a gentle and even opening, ergonomically optimised multi-component handle sleeves.

Technical data

Areas of use

Electronics manufacturing and service, work on cable harnesses, precision engineering and laboratory work. The S1 version is also suitable for opening plastic cable connectors.

Standards and conformity

The pliers comply with DIN ISO 9654. According to the manufacturer they contain no substances of very high concern under REACH, and the RoHS directive does not apply to this product.
