Proximity Sensor SIEF-M30NB-NS-S-L - Festo 538321
Festo sensor for reliable monitoring of position, pressure or status in the pneumatic system.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Festo sensor for reliable monitoring of position, pressure or status in the pneumatic system. The key technical data of this genuine Festo article are listed below.
Technical data
| Design | round |
|---|---|
| Complies to standard | EN 60947-5-2 |
| Permission | RCM mark<br>c UL us - Listed (OL) |
| CE certificate (see declaration of conformity) | to EU EMC directive |
| Measurement principle | Inductive |
| Measurement switching distance [mm] | 20,0 |
| Secured safety distance [mm] | 16,20 |
| Reduction factors | aluminium = 1,0<br>stainless steel St 18/8 = 1,0<br>Copper = 1.0<br>brass = 1,0<br>Steel pc. 37 = 1.0 |
| ambient temperature [°C] | -30 to 85 |
| Repeatability [mm] | 0,40 |
| Control output | NPN |
| Switching element function | NO contact |
| Hysteresis [mm] | 0.6 to 3 |
| Max. switching frequency DC [Hz] | 1.500 |
| Max. output current [mA] | 200 |
| Voltage drop [V] | <= 1,8 V |
| Short circuit resistance | Cycling |
| Operating voltage range DC [V] | 10 to 30 |
| residual ripple | 10 % |
| Empty run current [mA] | <= 15 mA |
| Reverse polarity protection | for all electrical connections |
| Electrical connection | Fixcon<br>M12x1<br>3 pin<br>Plug |
| size | M30 |
| Fastening type | With locking nut |
| Torque [Nm] | 75 |
| Integration type | Part flush |
| Product weight [g] | 90,0 |
| Housing material | PBT<br>brass<br>Chrome plated |
| Switching status indicator | LED yellow |
| Protection category | IP67 |
| Noise immunity to magnetic fields | Magnetic direct and alternating field |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| Material information | Copper and PTFE-free |
| Weight | 0.095 kg |
| Manufacturer | Festo |
| Manufacturer Nr. | SIEF-M30NB-NS-S-L |
| EAN | 4052568175870 |
| HS-Code | 85365019 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Condition of article | New |
| Article authenticity | Original product |
| Material | Brass |
| Corrosion resistance class CRC | 2 - moderate corrosion stress |
| Norm | DIN EN 60947-5-2 |
| Series | SIEF |
| Protection class (IP) | IP67 |
| Temperature (max.) | 85 |
