SCS dual conductor coil cord 3 m, straight 3.4 mm plug, 1 megohm per conductor, gray - Desco 2370

Operators who move between bench, shelf and test equipment at a monitored ESD workstation need a longer grounding cord that keeps working even if one wire is damaged. The SCS 2370 coil cord reaches 3 m and carries two separate conductors, each with its own 1 megohm current limiting resistor. If one conductor fails, the path to ground is maintained through the second.

Key benefits

• 3 m length: twice the reach of the 1.5 m cord, for larger workstations
• Redundant grounding: two conductors, the operator stays grounded through one if the other is damaged
• Operator safety: a 1 megohm resistor in each conductor limits current on accidental contact with equipment line voltage
• Long service life: resistor connection strain relief tested to over 200,000 cycles in the ANSI/ESD S1.1 bending life test, against a requirement of 16,000
• Wider plug grip for easy insertion and removal at the monitor

Applications

Connecting dual-wire wrist straps to SCS dual-wire continuous monitors where the operator works further from the connection point, for example at wide assembly benches or when alternating between sitting and standing.

Standards

The resistors meet the resistance requirements of ANSI/ESD S20.20 and EIA 625, bending life is tested to ANSI/ESD S1.1. The cord forms part of a personnel grounding system to IEC 61340-5-1.
