SCS dual conductor coil cord 6 m, straight 3.4 mm plug, 1 megohm per conductor, gray - Desco 2371

At large workstations, test stands or assembly cells, operators often move several metres away from the monitor and still have to stay grounded at all times. The SCS 2371 coil cord reaches 6 m and carries two separate conductors, each with its own 1 megohm current limiting resistor. If one conductor fails, the path to ground is maintained through the second.

Key benefits

• 6 m length: the longest version in the series, four times the reach of the 1.5 m cord
• Redundant grounding: two conductors, the operator stays grounded through one if the other is damaged
• Operator safety: a 1 megohm resistor in each conductor limits current on accidental contact with equipment line voltage
• Long service life: resistor connection strain relief tested to over 200,000 cycles in the ANSI/ESD S1.1 bending life test, against a requirement of 16,000
• Wider plug grip for easy insertion and removal at the monitor

Applications

Connecting dual-wire wrist straps to SCS dual-wire continuous monitors where operators cover longer distances, for example in assembly cells, at large test stations or when working on assemblies inside control cabinets.

Standards

The resistors meet the resistance requirements of ANSI/ESD S20.20 and EIA 625, bending life is tested to ANSI/ESD S1.1. The cord forms part of a personnel grounding system to IEC 61340-5-1.
