SCS dual conductor coil cord 1.5 m, straight 3.4 mm plug, 1 megohm per conductor, gray - Desco 2360

Operators at a continuously monitored ESD workstation need a link between wrist strap and monitor that keeps working even if one wire is damaged. The SCS 2360 coil cord carries two separate conductors, each with its own 1 megohm current limiting resistor. If one conductor fails, the path to ground is maintained through the second.

Key benefits

• Redundant grounding: two conductors, the operator stays grounded through one if the other is damaged
• Operator safety: a 1 megohm resistor in each conductor limits current on accidental contact with equipment line voltage
• Long service life: resistor connection strain relief tested to over 200,000 cycles in the ANSI/ESD S1.1 bending life test, against a requirement of 16,000
• Wider plug grip for easy insertion and removal at the monitor
• 1.5 m length for stations with a short distance between operator and connection point

Applications

Connecting dual-wire wrist straps to SCS dual-wire continuous monitors at soldering, assembly and test stations in electronics manufacturing.

Standards

The resistors meet the resistance requirements of ANSI/ESD S20.20 and EIA 625, bending life is tested to ANSI/ESD S1.1. The cord forms part of a personnel grounding system to IEC 61340-5-1.
