USB Fluorescence Microscope 1.3 MP 10-70x and 200x UV 375nm - Dino-Lite AM4113FVT2

UV-A excitation at 375 nm for fluorescence imaging

The AM4113FVT2 is a Premier handheld microscope with UV illumination in the UV-A band. The 375 nm UV LEDs excite the sample and a built-in barrier filter blocks the reflected UV light so that an image with natural colours results. The shorter wavelength compared with the 400 nm variant suits samples that require UV-A excitation.

Key features

• UV LEDs at 375 nm to excite fluorescent samples
• Built-in barrier filter for natural colour rendering under UV
• Magnification 10-70x and 200x, maximum 200x
• 1.3 MP sensor at 1280 x 1024 pixels and up to 30 frames per second
• MicroTouch trigger and calibrated measurement through DinoCapture and DinoXcope

Technical data

• Sensor: 1.3 MP, 1280 x 1024
• Magnification: 10-70x and 200x (maximum 200x)
• Illumination: UV LEDs, 375 nm (UV-A)
• Interface: USB 2.0
• Barrier filter: yes, against reflected UV
• Polarizer: no
• Weight: approx. 0.105 kg

Applications

• Forensics and trace examination with UV-A fluorescence
• Materials and coating inspection under UV excitation
• Research and inspection with fluorescent markers

Compatibility and contents

Works with Dino-Lite MS-W1, RK-02 and MS08B stands and with the BL-CDW backlight. DinoCapture for Windows and DinoXcope for Mac software included.

Standards and origin

Made in Taiwan by AnMo Electronics. Customs code 90118000.
