For fine structures beyond standard magnification the Dino-Lite AM7515MT8A works in the 700-900x range. AMR reads the set magnification automatically, so measurements stay correct without recalibrating. Two year manufacturer warranty, shipped from Germany.
USB Digital Microscope 5 MP 700-900x with Coaxial Light - Dino-Lite AM7515MT8A
DINO-LITE
Original product
Net price (excl. VAT)
€954.00
Item
AM7515MT8A
Manufacturer no.
AM7515MT8A
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.AM7515MT8A
EAN4712805479146
Country of originTaiwan
Customs tariff number90118000
ConditionNew
Article
AM7515MT8A
Frequently Bought Together
-
This Item:
€954.00
-
ESD-safe precision stand with fine focus - Dino-Lite RK-06-AE
€214.80
Total price
For fine structures beyond standard magnification the Dino-Lite AM7515MT8A works in the 700-900x range.
What it does for you
- A 5 MP sensor and a 700-900x magnification range, so overview and detail come from the same device.
- AMR reads the set magnification automatically, so measurements stay correct without recalibrating.
- Flexible LED Control switches individual LED segments to take out cast shadows and hot spots.
- ESD safe housing for use at EPA workstations to IEC 61340-5-1.
- The MicroTouch trigger on the housing captures the image without shaking the camera.
- Wireless ready: with the WF-10 adapter the microscope runs cable free on tablet and phone.
Technical data
| Property | Value |
|---|---|
| Magnification | 700x ~ 900x |
| Working distance | Standard |
| Macro zoom | No |
| Lens type | Glass with anti-reflection coating |
| Sensor type | CMOS |
| Resolution | 5.0 Megapixel (2592x1944) |
| Frame rate | 30 fps (max 20fps video recording) |
| Illumination | White |
| Number of LEDs | 8 |
| LEDs switchable | Yes |
| Flexible LED Control | Yes |
| Polarizer | No |
| Infrared filter | IR cut-filter >650 nm |
| Emission filter | No |
| Diffuser cap | No |
| Magnification readout (AMR) | Yes |
| Measurement | Yes |
| Calibration | Yes |
| MicroTouch sensor | Yes |
| Magnification lock | Yes |
| Interface | USB 2.0 |
| Imaging standards | DirectShow, UVC |
| Wi-Fi | Wireless-ready, requires the WF-10 WiFi streamer (optional) |
| Operating system | Windows 7, 8, 10 & 11, MacOS 10.12 and up |
| Software | DinoCapture 2.0 (Windows), DinoXcope (Mac OS) |
| Housing | Metal housing |
| Dimensions | 10.7cm (L) x 3.2cm (D) |
| Weight | 139g |
| Cable length | 1.8m |
| ESD safe | Yes |
| Country of origin | Taiwan |
| Warranty | 2 years European warranty |
| Regulatory approval | CE, UKCA - available upon request - [email protected] |
| Package contents | Microscope, Carry pouch, software CD, user manual, quick guide, calibration target, front cover box |
Magnification, working distance and field of view
| Magnification | Working distance (mm) | Field of view X (mm) | Field of view Y (mm) | Depth of field (mm) |
|---|---|---|---|---|
| 700 | 6.4 | 0.56 | 0.400 | 0.01 |
| 750 | 6.3 | 0.52 | 0.375 | 0.01 |
| 800 | 6.1 | 0.48 | 0.350 | 0.009 |
| 850 | 6.0 | 0.46 | 0.330 | 0.009 |
| 900 | 5.9 | 0.43 | 0.315 | 0.008 |
Values without front cap, as published by the manufacturer.
Typical uses
- Electronics manufacturing and repair: solder joints, BGA edges, tracks, placement errors.
- Materials testing: fracture surfaces, welds, corrosion, microstructure.
- Quality control and incoming inspection: surface defects, burrs, coatings, dimensional checks.
| ESD version | ESD (antistatic) |
|---|---|
| Manufacturer Nr. | AM7515MT8A |
| Manufacturer | Dino-Lite |
| Country of Manufacture | Taiwan |
| EAN | 4712805479146 |
| ESD equipment | USB Mikroskop |
| Weight | 0.139000 |
| HS-Code | 90118000 |
| GPSR manufacturer information | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment, info@esd.equipment |
| Article authenticity | Original product |
| Condition of article | New |
| Warranty | 2 years |
| Material | Metal |
| Polarizer | No |
| Long Working Distance | No |
| Interface | USB 2.0 |
