Hybrid rework system with 8200 W of heating power, whose bottom heater spreads 6400 W across eight 800 W zones over 530 x 530 mm. Boards up to 530 x 610 mm fit, and placement accuracy reaches plus minus 25 µm. Alignment runs through a vision box with a 5 MP camera and a joystick for the X, Y and rotation axes.
HR550XL Hybrid Rework System 8200W mit besonders großem Platinenhalter - Ersa 0HR550XL
ERSA
Original product
Net price (excl. VAT)
€55,000.00
Item
ER-0HR550XL
Manufacturer no.
0HR550XL
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.0HR550XL
ConditionNew
Article
ER-0HR550XL
Frequently Bought Together
-
This Item:
€55,000.00
-
Suction Nozzle 4 mm for 0PL550 Placement System - Ersa 0PL500A-S004
€444.47
-
Micro Suction Nozzle Type 0510 for Rework Stations - Ersa 0IR5500-40
€141.75
Total price
Large multilayers and heavy copper pull the heat out of the joint. The Ersa HR 550XL answers with 6400 W of bottom heat spread over eight separately controlled 800 W zones across 530 x 530 mm, and a 1900 W hybrid top emitter working on 70 x 70 mm.
What the XL version is built for
- 8200 W of total heating power, of which 6400 W come from a bottom heater with eight 800 W zones over 530 x 530 mm.
- Boards up to 530 x 610 mm and beyond, which is 20.8 x 24 inches.
- Placement accuracy down to plus minus 25 µm, supported by a force sensor and computer aided placement CAP.
- Vision box with a 5 MP camera, wide field of 70 x 70 mm and tele field of 25 x 33 mm, plus two sided LED lighting in red and green.
- Joystick control unit for the X, Y and rotation axes, with the process run from Ersa HRSoft2.
- Component range from 0.2 x 0.4 mm to 70 x 70 mm, with 35 mm clearance below and 60 mm above.
Technical data
| Part number | 0HR550XL |
| Total heating power | 8200 W |
| Bottom heater | 6400 W, 8 zones of 800 W each, 530 x 530 mm |
| Top heater | 70 x 70 mm, 1900 W hybrid, 900 W infrared and 1000 W hot air |
| Supply | 400 V AC, three phase, 50 Hz, 16 A |
| Max. board size | 530 x 610 mm plus overhang, equal to 20.8 x 24 inches |
| Component size | 0.2 x 0.4 mm to 70 x 70 mm |
| Component clearance | 35 mm below, 60 mm above |
| Placement accuracy | plus minus 25 µm |
| Camera | Vision box with 5 MP, wide angle 70 x 70 mm, tele 25 x 33 mm |
| Lighting | Two sided LED in red and green |
| Temperature sensing | 1 digital contactless infrared sensor, 2 type K inputs, 1 Accu-TC sensor |
| Operation | Joystick for X, Y and rotation, computer aided placement CAP |
| Interface | Ethernet with 2 m RJ45 patch cable |
| Software | Ersa HRSoft2 |
Scope of delivery
- Laser pointer for component identification and board positioning
- Thermocouple holder and Accu-TC sensor
- Support rail with 2 pins
- Placement and desoldering nozzle, 5 mm outer diameter
- Placement and desoldering nozzle, 10 mm outer diameter
- Ethernet patch cable, 2 m
- Mount for use with the Ersa Dip and Print station
Use and compatibility
The HR 550XL targets power electronics, backplanes and large format assemblies where standard systems reach their thermal limit. A three phase 400 V, 16 A supply is a prerequisite. A mount for the Ersa Dip and Print station is provided.
| Manufacturer Nr. | 0HR550XL |
|---|---|
| Manufacturer | Ersa |
| GPSR manufacturer information | Bräunlich GmbH Am Heideberg 26, DE 06886 Lutherstadt Wittenberg, www.braeunlich-gmbh.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
