Micro Suction Nozzle Type 1020, Brass, 1.0 mm Inner Ø - Ersa 0IR5500-41
Rigid brass micro suction nozzle type 1020 for ERSA infrared and hybrid rework systems. 1.0 mm inner and 2.0 mm outer diameter for safely picking up the smallest components. Fits 0IR500, 0IR550, 0IR650 as well as 0HR600 and 0HR600/2.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The ERSA micro suction nozzle type 1020 is a rigid brass nozzle for precisely picking up and placing the smallest components during rework. With a 1.0 mm inner diameter and a 2.0 mm outer diameter, it handles densely packed SMD components and is designed for ERSA infrared and hybrid rework systems.
Technical data
| Type | 1020 |
|---|---|
| Design | rigid |
| Material | brass |
| Inner diameter | 1.0 mm |
| Outer diameter | 2.0 mm |
| Application | picking up the smallest components |
| Compatible with | 0IR500, 0IR550, 0IR650, 0HR600, 0HR600/2 |
| Weight | 0.1 kg |
| Manufacturer | Ersa |
| Manufacturer Nr. | 0IR5500-41 |
| GPSR manufacturer information | Ersa GmbH, Leonhard-Karl-Straße 24, DE-97877 Wertheim, www.kurtzersa.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| ESD version | TEC |
| ESD equipment | ESD Lötstationen |
Downloads
Datasheet
User Manual
Declaration of Conformity
