TUBELED_70 EVO machine light 300 mm, 14W, 1899 lm, 100°, 120-277V AC, IP69K - LED2WORK 156010-11
A powerful LED machine light with integrated driver for 120-277 V AC: 1899 lm at 12 W lamp power, 155 lm/W. IP67/IP69K against dust and high-pressure cleaning, ideal for direct mains supply.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The TUBELED_70 EVO AC is a powerful LED machine light with an integrated driver for direct connection to 120-277 V AC. With IP67/IP69K protection it is dust-tight and protected against high-pressure cleaning, delivering 1899 lm at 12 W lamp power, an efficiency of 155 lm/W.
Key benefits
- Integrated driver for direct connection to 120-277 V AC
- 1899 lm at 12 W lamp power, high efficiency of 155 lm/W
- Daylight white 5700K with colour rendering Ra >85 for even, flicker-free light
- IP67/IP69K, dust-tight and resistant to high-pressure cleaning
- Aluminium housing with shatter-resistant safety glass
- Service life over 100,000 h (L80/B10), low maintenance
Applications
For lighting work areas in machine tools and plants with a 120-277 V AC mains supply, including under harsh conditions with coolants, dust and high-pressure cleaning. Mounting accessories optional.
Technical data
| Model | TUBELED_70 EVO AC |
|---|---|
| Light source | SMD LED |
| Total power incl. driver | 14 W |
| Lamp power | 12 W |
| Luminous flux | 1899 lm |
| Luminous efficacy | 155 lm/W |
| Light colour | 5700K 3-step MacAdam |
| Colour rendering (Ra) | >85 |
| Beam angle | 100° |
| Supply voltage | 120-277 V AC ±10 %, 50-60 Hz, integrated driver |
| Connection | M12 S-coded, 3-pin |
| Protection rating | IP67/IP69K |
| Protection class | I |
| Operating temperature | -20 °C to +60 °C |
| Service life | > 100,000 h (L80/B10) |
| Housing material | aluminium, glass |
| Dimensions | 300 mm x 70 mm x 59.5 mm |
| Weight | 1100 g |
| Dimmable | no |
| Risk group (DIN EN 62471) | exempt group |
| Certifications | CE, UKCA, ETL Listed (5003529) |
| Made in | Germany |
| Manufacturer | LED2WORK |
| Manufacturer Nr. | 156010-11 |
| HS-Code | 94054243 |
| GPSR manufacturer information | LED2WORK GmbH, Stuttgarter Straße 13 A, 75179 Pforzheim www.led2work.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Norm | DIN EN 62471 |
| Control and dimming | Dimmable |
| Luminous flux (lumen) | 1899 lm |
| Power (W) | 14 W |
| Colour temperature | 5700K |
| Operating voltage | 120-277 V |
| Protection class (IP) | IP69K |
