SYSTEMLED EVO ECO LED system light 898mm 4000K, approx. 26W, IP40 - LED2WORK 155120-02

The SYSTEMLED EVO ECO is a German-made LED system light for demanding assembly, production and laboratory workplaces. Over a 898mm length it delivers 3980 lm of luminous flux in 4000K neutral white, creating the even, glare-free lighting that precise work needs.

Key benefits

• High efficiency: 173 lm/W efficacy from approx. 26W connected power keeps running costs low.
• Bright illumination: 3980 lm of luminous flux in 4000K neutral white for clearly visible work areas.
• Glare-free: micro-prism glare control and a 90° beam angle for an even light distribution.
• High colour fidelity: colour rendering >90 (typ. 95) with 3-step MacAdam consistency for reliable colour recognition.
• Easy mounting: a rear T-slot (slot size 8) fixes the light to common profile and carrier systems.
• Durable: a service life of > 100.000 h (L80/B10) and German manufacture for long-term reliability.

Technical data

• Model: SYSTEMLED EVO - ECO Neutralweiss
• Type: LED Systemleuchte
• Light source: SMD LED
• Total power incl. driver: ~26 W
• Lamp power: ~23 W
• Luminous flux: 3980 lm
• Luminous efficacy: 173 lm/W
• Light distribution: Direct
• Light colour: 4000K 3-step MacAdam
• Colour rendering (Ra): >90 (typ. 95)
• Supply voltage: 120-277V AC ± 10%, 50-60 Hz
• Connection: Wieland GST18
• Protection rating (IP): IP40
• Protection class: I
• Glare control: micro-prisms
• Beam angle: 90°
• Operating temperature: -10 °C - +50 °C
• Service life: > 100.000 h (L80/B10)
• Housing material: aluminium and PMMA
• Dimensions (L x H x W): 898 mm x 48 mm x 139 mm
• Weight: 2550 g
• Risk group (DIN EN 62471): Exempt group
• Certifications: CE, UKCA
• Dimmable: optional via accessory
• Made in: Germany

Applications

Ideal for assembly stations, production lines, laboratories and inspection areas that call for even, colour-accurate lighting. Optional mounting accessories extend the fitting options, and the light can be dimmed and switched via an optional accessory.

Supply and standards

Connected via Wieland GST18 for safe, low-tool installation. Marked CE and UKCA, exempt group per DIN EN 62471. Made in Germany.
