SYSTEMLED EVO ECO LED system light 898mm 4000K, approx. 26W, IP40 - LED2WORK 155120-02

LED2WORK ✓ Original product Brand new Made in Germany

The SYSTEMLED EVO ECO is a German-made LED system light, 898mm long, for assembly, laboratory and production workstations. It delivers 3980 lm of luminous flux in 4000K neutral white at 173 lm/W efficacy, and its 90° beam angle and micro-prism glare control provide even, glare-free illumination. A service life of > 100.000 h (L80/B10) keeps maintenance costs low.

Net
€251.24
excl. VAT
Item L2W-155120-02
Manufacturer no. 155120-02
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The SYSTEMLED EVO ECO is a German-made LED system light for demanding assembly, production and laboratory workplaces. Over a 898mm length it delivers 3980 lm of luminous flux in 4000K neutral white, creating the even, glare-free lighting that precise work needs.

Key benefits

  • High efficiency: 173 lm/W efficacy from approx. 26W connected power keeps running costs low.
  • Bright illumination: 3980 lm of luminous flux in 4000K neutral white for clearly visible work areas.
  • Glare-free: micro-prism glare control and a 90° beam angle for an even light distribution.
  • High colour fidelity: colour rendering >90 (typ. 95) with 3-step MacAdam consistency for reliable colour recognition.
  • Easy mounting: a rear T-slot (slot size 8) fixes the light to common profile and carrier systems.
  • Durable: a service life of > 100.000 h (L80/B10) and German manufacture for long-term reliability.

Applications

Ideal for assembly stations, production lines, laboratories and inspection areas that call for even, colour-accurate lighting. Optional mounting accessories extend the fitting options, and the light can be dimmed and switched via an optional accessory.

Supply and standards

Connected via Wieland GST18 for safe, low-tool installation. Marked CE and UKCA, exempt group per DIN EN 62471. Made in Germany.

Technical data

ModelSYSTEMLED EVO - ECO Neutralweiss
TypeLED Systemleuchte
Light sourceSMD LED
Total power incl. driver~26 W
Lamp power~23 W
Luminous flux3980 lm
Luminous efficacy173 lm/W
Light distributionDirect
Light colour4000K 3-step MacAdam
Colour rendering (Ra)>90 (typ. 95)
Supply voltage120-277V AC ± 10%, 50-60 Hz
ConnectionWieland GST18
Protection rating (IP)IP40
Protection classI
Glare controlmicro-prisms
Beam angle90°
Operating temperature-10 °C - +50 °C
Service life> 100.000 h (L80/B10)
Housing materialaluminium and PMMA
Dimensions (L x H x W)898 mm x 48 mm x 139 mm
Weight2550 g
Risk group (DIN EN 62471)Exempt group
CertificationsCE, UKCA
Dimmableoptional via accessory
Made inGermany
ManufacturerLED2WORK
Manufacturer Nr.155120-02
HS-Code94054239
GPSR manufacturer informationLED2WORK GmbH, Stuttgarter Straße 13 A, 75179 Pforzheim www.led2work.com
Condition of articleNew
Article authenticityOriginal product
Country of ManufactureGermany
NormDIN EN 62471
Control and dimmingSwitchable (HF)
Luminous flux (lumen)3980 lm
Power (W)26 W
Colour temperature4000K
Mounting typeT-slot / profile
Operating voltage120-277 V
Protection class (IP)IP40
