MiniTweez Removal Tip 10 mm for D-Pak, SOT, TSOP and SOIC, for MT-200 - PACE 1130-1007
Tweezer tip with 10 mm blade for the MT-200 MiniTweez. For D-Pak, SOT, TSOP and mid-length SOIC, reflowing both lead rows together.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
SOIC-14 and SOIC-16 or mid-size TSOPs are too long for short blades. With a 10 mm blade these MT-200 tips fully cover both lead rows of such packages, so every lead reflows at once and the part lifts off without tilting.
Benefits
- 10 mm blade for mid-length SOIC and TSOP
- Both tips heat the opposite terminations at the same time, the part is lifted in the same grip
- No switching between iron and tweezers, shorter heat exposure for the board
Specifications
Applications
- Swapping SOIC-14/16 logic and driver ICs
- Removing mid-size TSOP packages
- Repair of industrial and automotive electronics
Compatibility
- PACE MT-200 MiniTweez thermal tweezers
Technical data
| Part number | 1130-1007 |
|---|---|
| Type | Tweezer tip (MiniTweez thermal tweezers) |
| Components per PACE | D-Pak, SOT, TSOP, SOIC |
| Blade size | 10 mm |
| Handpiece | PACE MT-200 MiniTweez |
| Sales unit | 1 piece |
| Weight | 0.03 kg |
| Manufacturer | PACE |
| Manufacturer Nr. | 1130-1007 |
| HS-Code | 85159080 |
| GPSR manufacturer information | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | United States |
| Tip diameter/width [mm] | 10 |
| Soldering tip shape | Pinzettenspitze |
| Series | MT-200 |
Downloads
Datasheet
User Manual
Catalogue
