BR3 tape reel holder for taped radial components 12.7 mm pitch Supercut - Iteco 7915160

Radial capacitors and resistors normally arrive on tape with 12.7 mm pitch, that is half an inch, while the Supercut cutting machine is built for loose components. This BR3 reel holder carries the reel and guides the 12.7 mm tape into the cutting zone, so an existing machine handles taped parts without any conversion work.

Operating features

• For 12.7 mm tape pitch - covers the standard taping of radial components, for 15 mm pitch Iteco supplies version 7915.159.
• Retrofittable - the holder is fitted to an existing Supercut cutting machine, the machine itself stays unchanged.
• Guided feed - the tape enters the cutting zone without jamming, so loose parts no longer have to be sorted.
• Up to 3000 components per hour - transfer and ejection of the cut components run automatically, with no downtime caused by manual loading.
• Adjustable cut length - the lead length is set on the machine guide and the transfer speed remains steplessly adjustable.

Technical data

Applications

Production lines that buy radial components on standard 12.7 mm tape and want to keep using an existing Supercut, repair and prototype work with changing reels, and small batches that do not justify a dedicated taped component machine.

Compatibility and scope of supply

The reel holder fits the Supercut cutting machine, supplied by Iteco under 7915.147N in the 115 V version and under 7915.148N in the 230 V version. For tapes with 15 mm pitch the reel holder 7915.159 is intended, and for the Superform range the BR6 holder arm under 7915.185. Supplied as a reel holder without machine. Made in Italy.
