Extraction unit for gases and odours 1,000 m³/h ACD 1200 MD.18 A28 - ULT ACD 1200.0-MD.18.01.1010
The ACD 1200 MD.18 A28 works with storage filters that are replaced once saturated and reaches 1,000 m³/h at 1,700 Pa from an EC blower rated 0.86 kW. Maximum figures are 1,500 m³/h and 3,250 Pa vacuum at a noise level of 55 dB(A) and protection class IP54. Air flow is adjusted steplessly, and the two adsorption cassettes bind gases, vapours and odours with 12 kg and 16 kg of activated carbon.
Net
excl. VAT
€7,349.57
Item
WL28180
Manufacturer no.
ACD 1200.0-MD.18.01.1010
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
With gaseous contaminants it is not only the separation rate that counts but the amount of adsorption media inside the unit. The ULT ACD 1200 MD.18 A28 relies on storage filters with two adsorption cassettes of 12 kg and 16 kg of activated carbon and adds 1,000 m³/h at 1,700 Pa so that capture at source actually works.
Benefits
- Nominal duty point 1,000 m³/h at 1,700 Pa, maximum 1,500 m³/h and up to 3,250 Pa vacuum
- EC blower rated 0.86 kW at 230 V and 4.8 A nominal current
- Stepless volume flow control via the potentiometer on the control panel
- A28 filter configuration with a G4 Z-Line filter as dust pre-stage and 28 kg of activated carbon in two cassettes
- Noise level 55 dB(A) and protection class IP54, mobile on castors at a unit weight of 155 kg
- Exchange filter system with quick-lock catches for a tool-free filter change
Applications
Extraction of gases, vapours and odours during bonding, laminating, painting, printing, pre-treatment, cleaning, mixing and casting. The storage filter concept suits places with a steady gas load where regenerating processes are not an option. The unit roof carries a Ø 160 mm mount for an extraction arm.
Compatibility and scope of delivery
Equipped with EC blower, volume flow control and the A28 main filter module: Z-Line filter G4-02 (ULT 4-00310), adsorption filter cassette A12 with 12 kg of activated carbon (ULT 4-00401) and adsorption filter cassette A16 with 16 kg of activated carbon (ULT 4-00399). For gas mixtures where activated carbon alone is not enough, two chemisorption configurations are available: AC36 with 50 percent chemisorption media (ULT 9-00096) and C41 with 100 percent chemisorption media (ULT 9-00097). These are storage filters, replaced once saturated. The filtered clean gas may be returned to the workspace. With carcinogenic, mutagenic or reprotoxic substances recirculation is not permitted, in that case the exhaust spigot is fitted on the outlet side.
Technical data
| Item number | WL28180 |
|---|---|
| Model | ACD 1200 MD.18 A28 |
| Manufacturer | ULT |
| Manufacturer item number | ACD 1200.0-MD.18.01.1010 |
| Order unit | piece |
| Type of vacuum generator | EC blower |
| Motor rating | 0.86 kW |
| Nominal voltage | 1~230 V |
| Nominal frequency | 50/60 Hz |
| Nominal current | 4.8 A |
| Nominal duty point | 1,000 m³/h at 1,700 Pa |
| Volume flow max. | 1,500 m³/h |
| Vacuum max. | 3,250 Pa |
| Protection class | IP54 |
| Noise level | 55 dB(A), per technical documentation 55 to 65 dB(A) at 50 to 100 percent air performance |
| Dimensions (W x D x H) | 790 x 820 x 1,040 mm |
| Weight | 155 kg |
| Filter stage 1 | Z-Line filter G4-02, ISO Coarse 90 percent to ISO 16890 (ULT 4-00310) |
| Filter stage 2 | Adsorption filter cassette A12 top, 12 kg activated carbon (ULT 4-00401) |
| Filter stage 3 | Adsorption filter cassette A16 bottom, 16 kg activated carbon (ULT 4-00399) |
| Inlet spigot | 1 x Ø 150 mm collar at the upper rear, alternatively 1 x Ø 160 mm collar on the unit roof |
| Exhaust air | Outlet grille at the lower rear, optional 1 x Ø 200 mm collar |
| Mains cable | 5.0 m, EU version CEE 7/7 |
| Options | DN200 exhaust connection (ULT 9-00089), SUB D9 interface (ULT 9-00090), operating hour meter (ULT 9-00093), outlet silencer (ULT 9-00099) |
| Manufacturer Nr. | ACD 1200.0-MD.18.01.1010 |
| HS-Code | 84213925 |
| GPSR manufacturer information | ULT AG Am Göpelteich 1 DE-02708 Löbau www.ult.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Power (W) | 860 W |
| Protection class (IP) | IP54 |
| Filter class | G4 |
| Airflow [m³/h] | 1000 |
| Max. vacuum [Pa] | 3250 |
| Sound pressure level [dB(A)] | 55 |
