The dented hoof form keeps a small solder reservoir right at the lead row while drag soldering fine pitch packages. With a 2.0 mm working face, a 13 mm tip and a self regulating 420 to 475 °C band it suits fast work on QFP and SOIC leads. It fits the SHP-T hand piece of the TMT-5000S-1 and TMT-5000S-2 systems.
Soldering tip hoof with dent 45° 2.0 mm T series - Thermaltronics T80WV020
THERMALTRONICS Original product
Net price (excl. VAT)
€24.29
Item WL38397
Manufacturer no. T80WV020
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.T80WV020
ConditionNew
Article
WL38397
Frequently Bought Together
- This Item: €24.29
- Soldering tip conical 1.0 mm T series 325-358 °C - Thermaltronics T60C010 €13.25
- Soldering tip bevelled 60 degrees 1.0 mm long reach - Thermaltronics TM70LR400 €13.25
Total price
When dragging along a lead row, tip geometry decides how much solder travels with the tip and how much stays behind as a bridge. The hoof form with a dent, ground at 45°, holds a defined amount of solder and releases it in a controlled way across a 2.0 mm face.
Benefits
- The dent in the hoof retains molten solder at the tip and cuts down bridging during drag soldering
- 2.0 mm working face on a 13 mm tip stays visible even in densely populated areas
- Curie point technology without sensor or controller, working band 420-475 °C
- High thermal output for lead-free alloys and demanding joints
- RoHS compliant
Technical data
| Item number | WL38397 |
| Model | T80WV020 |
| Manufacturer | Thermaltronics |
| Manufacturer item number | T80WV020 |
| Product series | T tip series, 420-475 °C |
| Temperature range | 420-475 °C |
| Type | Soldering tip |
| Tip shape | Hoof with dent, 45° |
| Tip length | 13 mm (0.51 in) |
| Tip width | 2 mm (0.08 in) |
| Suitable hand piece | SHP-T |
| Suitable systems | TMT-5000S-1, TMT-5000S-2 |
| Order unit | Piece |
| Dimensions with packaging (LxWxH) | 117 mm x 33 mm x 13 mm (4.6 in x 1.3 in x 0.5 in) |
| Weight | 0.1 kg |
| Design | RoHS compliant, lead-free capable |
Applications
Drag soldering QFP and SOIC lead rows, rework on fine pitch parts, placing and correcting individual joints in prototype work.
Compatibility and scope of delivery
For the SHP-T hand piece of the TMT-5000S-1 and TMT-5000S-2 soldering systems. One tip cartridge is supplied, hand piece and power unit are ordered separately.
| Manufacturer Nr. | T80WV020 |
|---|---|
| Manufacturer | Thermaltronics |
| Weight | 0.100000 |
| GPSR manufacturer information | AMS Ltd, Unit 3 Norse Trade Park, Congleton CW12 1GW, www.ams-electronics.co.uk |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
