Crimp system pliers for exchangeable crimping dies 97 49 XX, without die, 200 mm - Knipex 97 43 200 A

Anyone working with many connector types does not want a separate tool for each of them. The 97 43 200 A crimp system pliers are the base tool for the crimping dies of the 97 49 XX range and thus cover almost 1000 connector and contact types with a single tool.

Benefits

• Can be used with all 97 49 XX crimping dies and locators, one tool for almost 1000 connector and contact types.
• Almost parallel crimping movement, which gives an even crimp profile across the whole pressing area.
• Trigger lock according to IEC 60352, the pliers release only after a completed crimping cycle and keep quality consistent.
• Crimping pressure set precisely and calibrated at the factory, readjustable if required.
• Force amplification through lever transmission for fatigue-free work even in long series.
• Tool body of high grade chrome vanadium electric steel, oil-hardened, pliers and head with black oxide finish.

Areas of use

Connector assembly in control cabinet and control system building, test departments, sample production and maintenance. The matching crimping die is ordered separately for each connector type, and the manufacturer offers dies on request for applications beyond the standard range. The 97 49 xx dies are not compatible with the KNIPEX MultiCrimp 97 33 01, 97 33 02 and 97 33 03.

Standards and conformity

The trigger lock complies with IEC 60352. According to the manufacturer the product contains substances of very high concern under REACH, the RoHS directive does not apply.
