High leverage diagonal cutter VDE 1000 V, chrome-plated, hard wire up to 3.5 mm, 250 mm - Knipex 74 06 250
High leverage diagonal cutter, 250 mm long, for hard materials on live parts. The induction-hardened precision cutting edges of approx. 64 HRC cut medium-hard wire up to 3.5 mm and piano wire up to 3.0 mm. The multi-component grips are tested to DIN EN 60900 for work up to 1000 V, weight 453 g.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Anyone cutting wire and spring steel on switchgear without isolating the installation needs a tool with tested insulation and a powerful cutting edge. The 74 06 250 high leverage diagonal cutter cuts hard wire up to 3.5 mm and carries multi-component grips tested to DIN EN 60900 for work up to 1000 V.
Benefits
- Built for very tough, continuous use, pliers and head are chrome-plated.
- High cutting performance with little effort thanks to the matched cutting edge angle and transmission ratio.
- Precision cutting edges additionally induction-hardened to approx. 64 HRC, suitable for all wire types including piano wire up to 3.0 mm.
- Insulated multi-component grips, VDE tested to DIN EN 60900 and IEC 60900 for work up to 1000 V.
- 250 mm overall length at 453 g, the long lever reduces the hand force needed for medium-hard wire of 4.6 mm.
Areas of use
Electrical installation, control cabinet and plant construction and maintenance, wherever heavy cores, binding wire or spring steel have to be cut close to live parts.
Standards and conformity
The tool is made to DIN ISO 5749 and tested to DIN EN 60900 and IEC 60900 for live working up to 1000 V. According to the manufacturer it contains no substances of very high concern under REACH, the RoHS directive does not apply.
Technical data
| EAN | 4003773041955 |
|---|---|
| Pliers | chrome-plated |
| Head | chrome-plated |
| Handles | insulated with multi-component grips, VDE tested |
| Weight | 453 g |
| Dimensions | 250 x 61.3 x 28.8 mm |
| Standard | DIN ISO 5749, DIN EN 60900, IEC 60900 |
| REACH conformity | contains no SVHC |
| RoHS conformity | not applicable |
| Cutting capacity medium-hard wire (diameter) | Ø 4.6 mm |
| Cutting capacity hard wire (diameter) | Ø 3.5 mm |
| Cutting capacity piano wire (diameter) | Ø 3.0 mm |
| VDE tested | yes |
| Manufacturer | Knipex |
| Manufacturer Nr. | 74 06 250 |
| HS-Code | 82032000 |
| GPSR manufacturer information | KNIPEX-Werk Oberkamper Strasse 13 DE-42349 Wuppertal-Cronenberg www.knipex.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Height | 28,8 mm |
| Width | 61,3 mm |
| Norm | DIN EN IEC 60900, DIN ISO 5749 |
| Certification | IEC 60900 |
| Overall length [mm] | 250 |
