Cable shears with opening spring for copper and aluminium cables up to Ø 15 mm, burnished, 165 mm - Knipex 95 21 165
Cable shears with opening spring for fine-stranded multi-core copper and aluminium cables up to Ø 15 mm, equivalent to 50 mm² and AWG 1/0. The spring opens the blades after every cut, so the second hand can stay on the cable. Burnished finish with plastic coated handles, 165 mm long, 215 g.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
When cutting one core after another, every manual reopening of the shears costs time. The 95 21 165 cable shears have an opening spring and cut fine-stranded multi-core copper and aluminium cables up to Ø 15 mm, that is up to 50 mm², smoothly and without crushing.
Benefits
- Opening spring, the blades open by themselves after every cut, which speeds up repetitive work.
- Cuts fine-stranded multi-core copper and aluminium cables up to Ø 15 mm, that is 50 mm² or AWG 1/0.
- Clean and smooth cut without crushing and deformation, the core structure stays intact.
- Easy cutting with one-hand operation, the second hand stays free for the cable.
- Precision-ground hardened blades for a long service life.
- Adjustable bolted joint with self-retaining screw, plus a guard against pinched fingers.
Areas of use
Electrical installation, control cabinet and plant construction as well as service work on flexible cables. According to the manufacturer the shears are not suitable for steel wire and hard drawn copper conductors.
Standards and conformity
The manufacturer does not state a tool standard for this product, it is not an insulated VDE version. According to the manufacturer the shears contain no substances of very high concern under REACH. The RoHS directive does not apply.
Technical data
| EAN | 4003773069805 |
|---|---|
| Shears | burnished |
| Handles | plastic coated |
| Weight | 215 g |
| Dimensions | 165 x 42 x 14 mm |
| Cutting capacity copper cable, stranded | Ø 15 mm |
| AWG | 1 / 0 |
| REACH conformity | contains no SVHC |
| RoHS conformity | not applicable |
| Manufacturer | Knipex |
| Manufacturer Nr. | 95 21 165 |
| GPSR manufacturer information | KNIPEX-Werk Oberkamper Strasse 13 DE-42349 Wuppertal-Cronenberg www.knipex.de |
| Condition of article | New |
| Article authenticity | Original product |
| Height | 14 mm |
| Width | 42 mm |
| Overall length [mm] | 165 |
