Cable shears for stranded copper and aluminium multi-core cables up to Ø 15 mm or 50 mm², equal to AWG 1/0. The precision-ground hardened blades cut cleanly without crushing and the opening spring returns the tool to its starting position after every cut. The handles are insulated and VDE tested to DIN EN 60900 and IEC 60900, 275 g at 165 mm length.
Cable shears VDE tested with opening spring for Cu and Al cables up to Ø 15 mm, 165 mm - Knipex 95 26 165
KNIPEX
Original product
Net price (excl. VAT)
€51.12
Item
WL47687
Manufacturer no.
95 26 165
1000 V · IEC 60900
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.95 26 165
EAN4003773069980
ConditionNew
Article
WL47687
Frequently Bought Together
Cutting one cable after another in a control cabinet goes faster when the shears open again by themselves. The 95 26 165 cable shears have an opening spring for exactly that and cut stranded copper and aluminium multi-core cables up to Ø 15 mm, that is up to 50 mm².
Benefits
- Clean and smooth cut up to Ø 15 mm, the cable is not crushed and the conductor cross-section is preserved.
- Opening spring for fast repetitive work, the shears return to the starting position after every cut.
- Easy cutting with one-hand operation, also in poorly accessible places inside a cabinet.
- Precision-ground hardened blades for a long service life.
- Adjustable self-retaining bolted joint, so blade clearance can be corrected over the service life.
- Handles insulated with multi-component grips, VDE tested to DIN EN 60900 and IEC 60900, plus a guard.
Technical data
| EAN | 4003773069980 |
|---|---|
| Shears | chrome-plated |
| Handles | insulated with multi-component grips, VDE tested |
| Weight | 275 g |
| Dimensions | 165 x 63 x 26 mm |
| Standard | DIN EN 60900, IEC 60900 |
| Cutting capacity Cu cable, stranded | Ø 15 mm |
| AWG | 1 / 0 |
| VDE tested | yes |
| REACH conformity | contains no SVHC |
| RoHS conformity | not applicable |
Areas of use
Electrical installation, control cabinet and control system building, service and maintenance on low voltage installations. The shears are not suitable for steel wire or hard drawn copper conductors.
Standards and conformity
The shears are VDE tested to DIN EN 60900 and IEC 60900 and are therefore intended for live working on low voltage installations. According to the manufacturer they contain no substances of very high concern under REACH, the RoHS directive does not apply.
| Norm | DIN EN IEC 60900 |
|---|---|
| Certification | IEC 60900 |
| Manufacturer Nr. | 95 26 165 |
| Manufacturer | Knipex |
| EAN | 4003773069980 |
| Weight | 0.275000 |
| Height | 26 mm |
| Width | 63 mm |
| GPSR manufacturer information | KNIPEX-Werk Oberkamper Strasse 13 DE-42349 Wuppertal-Cronenberg www.knipex.de |
| Article authenticity | Original product |
| Condition of article | New |
| Overall length [mm] | 165.000000 |
