Festo sensor for reliable monitoring of position, pressure or status in the pneumatic system.
Proximity Sensor SIES-8M-PO-24V-K-7,5-OE - Festo 551391
FESTO
Original product
Net price (excl. VAT)
€67.10
Item
FES-551391
Manufacturer no.
SIES-8M-PO-24V-K-7,5-OE
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.SIES-8M-PO-24V-K-7,5-OE
EAN4052568094881
Customs tariff number85365019
ConditionNew
Article
FES-551391
Frequently Bought Together
-
This Item:
€67.10
-
Cover Kit EASC-S1-33-400 - Festo 562721
€151.17
-
Sensor Rail EAPR-S1-S-33-400/430-S - Festo 562625
€55.13
Total price
Festo sensor for reliable monitoring of position, pressure or status in the pneumatic system. The key technical data of this genuine Festo article are listed below.
| Complies to standard | EN 60947-5-2 |
| Permission | RCM mark<br>c UL us - Listed (OL) |
| CE certificate (see declaration of conformity) | to EU EMC directive |
| Material information | Copper and PTFE-free<br>RoHs compliant |
| Measurement switching distance [mm] | 1,5 |
| Reduction factors | Steel pc. 37 = 1.0<br>aluminium = 0,62<br>stainless steel V2A = 0,95<br>Copper = 0.6<br>brass = 0,72 |
| ambient temperature [°C] | -25 to 70 |
| Control output | PNP |
| Switching element function | NC contact |
| Max. switching frequency [Hz] | 4.500 |
| Short circuit resistance | Cycling |
| Operating voltage range DC [V] | 10 to 30 |
| Empty run current [mA] | <= 10 mA |
| Reverse polarity protection | for all electrical connections |
| Electrical connection | 3-wire<br>cable |
| Cable length [MTR] | 7,5 |
| Cable sleeve material | TPE-U(PU) |
| size | Slot 8 |
| Fastening type | Insertable from above into the slot<br>Permanently screwed<br>Flush with T-slot |
| Housing material | PA<br>PUR<br>High-alloyed stainless steels |
| Switching status indicator | LED yellow |
| Protection category | IP65<br>IP67 |
| Max. output current [mA] | 150 |
| Design | For T-slot |
| KC-mark | KC-EMV |
| Repeatability at constant conditions | <= 0.05 mm, side approaching |
| Connection outlet direction | along |
| Test conditions line | Bending radius strength to Festo standard<br>Cable track: 5 million cycles, bending radius 75 mm<br>Test conditions on request |
| Line properties | Standard+cable track |
| Ambient temperature for moving cable placements [°C] | -5 to 70 |
| Insulation voltage [V] | 50 |
| Surge voltage strength [kV] | 0,8 |
| Degree of contamination | 3 |
| Norm | DIN EN 60947-5-2 |
|---|---|
| Manufacturer Nr. | SIES-8M-PO-24V-K-7,5-OE |
| Manufacturer | Festo |
| EAN | 4052568094881 |
| Weight | 0.100000 |
| HS-Code | 85365019 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Temperature (max.) | 70 |
| Material | Stainless steel |
| Protection rating | IP65 |
| Series | SIES |
| Design | For T-slot |
| Position sensing | No |
