Bosch Rexroth tool and parts presentation covers ESD-compliant tool holders, balancer springs, side panels, tool shelves, and air bars for use in manual assembly systems. Tool holders are available in various diameters: D52, D91, and D95 with cup inserts in different depths (D52-9, D52-15, D91-32 mm) as well as oval cup inserts (D91-OVAL53-L100, D91-OVAL-L136). All ESD-version tool holders (marked "ESD") are designed for use in EPA zones per DIN EN 61340-5-1. Balancer springs for loads of 0.4-1 kg, 1-2 kg, and 2-4 kg, plus 1.2-2.5 kg (G1/4 port), relieve operators of tool weight during repetitive assembly tasks.
- 24 items
- 1 manufacturer
- Net prices plus VAT
Buying guide
How to choose Tool and Parts Supply
What matters when choosing: properties, comparison and typical applications.
Technical features
Tool holders and cup inserts overview
| Type | Diameter / format | ESD | Part no. |
|---|---|---|---|
| Tool holder L105 | L105 mm | Yes | 3842544768 |
| Tool holder D52 | D52 mm | Yes | 3842544832 |
| Tool holder D91 | D91 mm | Yes | 3842544833 |
| Tool holder D95 | D95 mm | Yes | 3842544772 |
| Cup insert D52-9 | D52 x 9 mm | Yes | 3842544834 |
| Cup insert D52-15 W BASE | D52 x 15 mm | Yes | 3842544836 |
| Cup insert D91-OVAL-L136 | Oval L136 mm | Yes | 3842546745 |
Typical applications
Typical applications: Tool presentation at assembly workstations in Bosch Rexroth profile systems, soldering iron holders and small-parts receptacles at ESD workstations, spring-suspended tool holding for repetitive handling tasks, adhesive and tape supply, and ergonomic parts access from grab bin shelving systems.
