Electric screwdriver 230 V push start 3.8 - 7.0 Nm, 650 rpm, with pistol grip - Delvo DLV70A06P-ABK

Screws from 5 mm upwards call for a tool that absorbs the reaction force and still shuts off at the preset value. This screwdriver tightens with 3.8 to 7.0 Nm and is held securely with the supplied DLW2300 pistol grip.

Benefits

• Push to start, the tool runs as soon as it is set on the screw. Tapping screws from 4.5 to 6.0 mm are covered as well.
• Direct connection to 230 V AC, no control unit or power supply is needed at the bench.
• Torque adjustable without steps from 3.8 - 7.0 Nm for machine screws from 5.0 - 8.0 mm. Torque is set steplessly on the adjustment ring, and the cover over it keeps the set value from being changed by accident.
• The detachable DLW2300 pistol grip is part of the delivery and puts the hand behind the driving axis, and it comes off in seconds for tight spots.
• Bit grounding is fitted as standard, so charge is led away through the tool instead of through the assembly. At ESD protected workstations nothing has to be retrofitted.
• Rated for cyclic work with 0.5 s on and 3.5 s off, which matches the rhythm of a manual assembly station. 3 m cord, 870 g with pistol grip at around 45 W, brushless motor with shut-off clutch and a design that conforms to the RoHS Directive.

Technical data

Applications

Final assembly of larger units in machine, device and vehicle building, joints in sheet metal, castings and profile parts.

Matching accessories

Bits with a 4 mm shank are taken by the ADA-HR4-D63 adapter. The BAL-0515 and BAL-1020 tool balancers carry the tool weight, and the SGR-14 and SGR-23 screw grids keep the screws ready at the bench.
