Electric screwdriver push start 2.0 - 4.5 Nm, nine speed levels, ESD - Delvo DLV45S06P-AYK

When an assembly needs a fixed number of screws and none may be missing, a tool that counts along earns its place. This screwdriver works between 2.0 and 4.5 Nm, keeps the speed constant through automatic control and reports every joint to the production control system through PNP signals.

Benefits

• Automatic speed control keeps the set speed even under load, so the result stays the same across a whole shift.
• Built-in screw counting with driving time monitoring, a missing screw shows up at the station. Results are returned through inputs and outputs of PNP signal type.
• Nine speed levels from Lv1 to Lv9 between 220 and 650 rpm, set with the optional RC1000 remote controller, which also handles auto reverse and the joint in up to three stages.
• Torque adjustable without steps from 2.0 to 4.5 Nm for machine screws from 4.5 to 6.0 mm and tapping screws from 4.0 to 5.0 mm.
• ESD protection structure according to the manufacturer, together with a brushless motor that needs no carbon brush changes.
• 860 g with the pistol grip at around 44 W, supplied from the DEA0151N-AZ or DEA0241N-AZ power unit.

Applications

Cycled assembly lines, test and final assembly stations and production areas with a documentation duty, where screws are counted and timed and the workstation is ESD protected.

Matching accessories

The RC1000 remote controller sets the speed levels, the counting function and the sequence. The DEA0151N-AZ or DEA0241N-AZ power unit supplies the tool. Bits with a 4 mm shank are taken by the ADA-HR4-D63 adapter, the BAL-0515 and BAL-1020 tool balancers carry the tool weight and the SGR-14 and SGR-23 screw grids keep the screws ready.
