ESD positioning tweezers, angled 35 degrees, fine 0.6 mm tip, dissipative stainless steel, 120 mm - Knipex 92 16 02 ESD

The smaller the component, the finer the tip has to grip. The 92 16 02 ESD positioning tweezers work with a tip width (A) of 0.6 mm and tips angled at 35 degrees, and their tested black epoxy coating keeps the surface resistance between 10^3 and 10^9 ohms.

Benefits

• Makes it easy to hold, insert and pull even the smallest elongated components.
• Very fine gripping surfaces with a tip width of 0.6 mm (A) and 0.8 mm (B) for the smallest package sizes.
• Tips angled at 35 degrees keep the gripping point in view even when working flat over the board.
• Tested black epoxy resin coating with a surface resistance between 10^3 and 10^9 ohms for controlled compensation of potential differences between operator and component.
• For through-hole technology (THT) and pin-in-hole technology (PIH) assembly.
• Antimagnetic to avoid electromagnetic damage, stainless steel, corrosion-resistant with very good acid resistance.

Areas of use

Manual assembly and repair of boards in an EPA, test field and laboratory. The fine angled tip suits small packages and places that sit between components already mounted.

Standards and conformity

The manufacturer states DIN EN 61340-5-1 for use in EPA areas, the tweezers are ESD tested. According to the manufacturer they contain no substances of very high concern under REACH, and the RoHS directive does not apply. No VDE test is declared.
