Placement nozzle with a 4 mm diameter for the placement head of the Ersa HR 600 and HR 600/2 hybrid rework systems. It picks up components by vacuum and sets them precisely onto the PCB. Suited to accurate placement of SMD components during rework.
Placement Nozzle 4 mm for HR 600 and HR 600/2 Rework Systems - Ersa 3HR600-06-022
ERSA Original product
Net price (excl. VAT)
€115.50
Item ER-3HR600-06-022
Manufacturer no. 3HR600-06-022
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3HR600-06-022
Country of originGermany
ConditionNew
Article
ER-3HR600-06-022
Frequently Bought Together
- This Item: €115.50
- Print Stencil Type 2.1 with Step, custom type, step size 3x3 to 40x40 mm, up to 100 pads - Ersa 0PR100-S00V2 €405.10
- Interchangeable Assembly for 12 mm Tape Width - Ersa 365856 €1,669.50
Total price
ERSA placement nozzle with a 4 mm diameter for the placement head of the HR 600 (0HR600) and HR 600/2 (0HR60/2) hybrid rework systems. The nozzle picks up components by vacuum and allows precise placement onto the PCB.
Technical data
| Type | Placement nozzle (vacuum pipette) |
|---|---|
| Nozzle diameter | 4 mm |
| Compatible with | Ersa HR 600 (0HR600), HR 600/2 (0HR60/2) |
| Use | Placement head for picking and setting SMD components |
| Manufacturer | Ersa |
| Article number | 3HR600-06-022 |
| Execution | TEC |
|---|---|
| Manufacturer Nr. | 3HR600-06-022 |
| Manufacturer | Ersa |
| Country of Manufacture | Germany |
| ESD equipment | ESD Lötstationen |
| Weight | 0.100000 |
| GPSR manufacturer information | Ersa GmbH, Leonhard Karl Str. 24, DE-97877 Wertheim, www.kurtzersa.de |
| Article authenticity | Original product |
| Condition of article | New |
