ESD electric screwdriver lever start 0.02 - 0.20 Nm, 500 - 750 rpm - Delvo DLV-7410-BME6

On connectors, boards and precision parts, too much tightening ruins the thread before the screw is home. This electric screwdriver works between 0.02 and 0.20 Nm and shuts off through its clutch as soon as the preset value is reached.

Benefits

• Torque infinitely adjustable from 0.02 to 0.20 Nm, fine enough for screws in the millimetre range.
• Shut-off clutch delivers the same tightening on every screw and spares soft threads.
• Lever start releases the spindle only once the bit is placed on the screw.
• Speed of 500 to 750 rpm, set at the control unit.
• Tool weight of only 230 g, which keeps long assembly sequences easy on the hand.
• Bit holder for 4 mm half-round shanks, the standard of this series.

Applications

Electronics manufacturing, connector and sensor assembly, precision engineering, optics, plus repair and test benches with small screws.

Matching accessories

The DLC-1213A-GGB and DLC-1213A-GG control units provide soft start and adjustable speed, and the DLW-9072 cable makes the connection. Bits of the DLB series with a 4 mm shank fit the holder, for instance DLB-2122 to DLB-2126 and DLB-2906IP-64. The BAL-0515 and BAL-1020 balancers take the weight off the bench. For more torque, the DLV-7420A BME6 covers 0.15 to 0.40 Nm.

ESD design

Housing and grip area conduct charges away in a controlled way. The screwdriver therefore suits workplaces inside an EPA according to IEC 61340-5-1.
