For cutting copper and aluminium cables, solid and stranded. Not suitable for steel wire, wire ropes and finest stranded (highly flexible) conductors. Hardened cutting edges with precision grinding. Cuts smoothly and cleanly without crushing. One-hand operation due to ratchet principle. Low power requirement due to very high transmission ratio. Two-speed ratchet drive for easy cutting. Easy handling due to low weight and compact design - can also be used in confined spaces. Pinch protection prevents crushing injuries. Fixed leg sheath with standing surface to rest on when cutting. Can be used with Al conductors up to 4 x 150 mm² sector cable. - Cutting value Cu-cable, stranded: 380mm² - Cutting value Cu-cable, stranded: Ø 52mm - MCM: 750
For cutting Cu- and Al-cables, solid and stranded
Not suitable for steel wire, wire ropes and finest stranded (highly flexible) conductors
Hardened cutting edges with precision grinding
Cuts smoothly and cleanly without crushing
One-hand operation due to ratchet principle
Low power requirement due to very high transmission ratio
Two-speed ratchet drive for easy cutting
Easy handling due to low weight and compact design - can also be used in confined spaces
Pinch protection prevents crushing injuries
Product details
item number
WL61901
model
95 31 280
manufacturer
KNIPEX
manufacturer item number
95 31 280
dimensions (LxWxH)
288 mm x 131 mm x 34 mm
dimensions with packaging (LxWxH)
330 mm x 165 mm x 40 mm
Packaging volume
2.178 dm³
order unit
piece
type of packaging
single pack
RoHS conform
no
surface
black lacquered
ESD safe
no
VDE
no
tool length
280 mm
type of handle
with multi-component sheaths
Cutting value copper cable, multistranded
380 mm²
Cutting value copper cable, multistranded (diameter)
