Robust. Handy. Stable... innovative ratchet drive. for cables up to 60 mm diameter. Fixed leg sheath with standing surface to rest on when cutting. Easy handling due to low weight (825 g) and compact design (320 mm length) - can also be used in confined spaces. Cuts Cu and Al cables up to a diameter of 60 mm in one and two-hand operation. Hardened cutting edges with precision grinding cut smoothly and cleanly without crushing. For cutting Cu and Al cables, solid and stranded. Innovative three-speed ring gear drive with high transmission ratio for easy cutting in one and two-hand operation. Not suitable for steel wire, wire ropes and finest stranded (highly flexible) conductors. - Cutting value Cu-cable, stranded: 600mm² - Cutting value Cu-cable, stranded: Ø 60mm - MCM: 1.200 - VDE-tested: Yes
- Fixed leg sheath with standing surface to rest on when cutting
- Easy handling due to low weight (825g) and compact design (320 mm length) - Can also be used in confined spaces
- Cuts Cu and Al cables up to a diameter of 60 mm in one and two-hand operation
- Hardened cutting edges with precision grinding cut smoothly and cleanly without crushing
- For cutting Cu and Al cables, single and multi-stranded
- Innovative three-speed gear rim drive with high transmission ratio for easy cutting in one and two-hand operation
- Not suitable for steel wire, wire ropes and finest stranded (highly flexible) conductors
Product details
| item number | WL61911 |
| model | 95 36 320 |
| manufacturer | KNIPEX |
| manufacturer item number | 95 36 320 |
| dimensions (LxWxH) | 400 mm x 188 mm x 39 mm |
| dimensions with packaging (LxWxH) | 400 mm x 188 mm x 39 mm |
| Packaging volume | 2.933 dm³ |
| order unit | piece |
| type of packaging | single pack |
| standards | DIN EN 60900 | IEC 60900 |
| RoHS conform | no |
| surface | black atramentised |
| VDE | yes |
| ESD safe | no |
| tool length | 320 mm |
| description head | polished |
| type of handle | VDE | insulated with multi-component sheaths, VDE-tested |
| Cutting value copper cable, multistranded | 600 mm² |
| Cutting value copper cable, multistranded (diameter) | 60 mm |
