Flat cylinder DZF, metric
Festo flat cylinders DZF (metric) are double-acting pneumatic cylinders with a rectangular flat profile and metric dimensions. The range covers 142 items in bore diameters from 12 to 32 mm and stroke lengths from 10 to 200 mm. The flat design allows installation where a round cylinder would be too tall. Variants -A-P-A (external thread, magnetic piston) and -P-A (magnetic piston without external thread) are available across the full range.
- 142 items
- 1 manufacturer
- Net prices plus VAT
Buying guide
How to choose Flat cylinder DZF, metric
What matters when choosing: properties, comparison and typical applications.
Technical features DZF metric
Product overview DZF
| Type | Bore Ø | Stroke | Variant |
|---|---|---|---|
| DZF-12-10-A-P-A | 12 mm | 10 mm | External thread, magnetic piston |
| DZF-12-200-P-A | 12 mm | 200 mm | No external thread, magnetic piston |
| DZF-18-...-A-P-A | 18 mm | 10-200 mm | External thread, magnetic piston |
| DZF-32-...-A-P-A | 32 mm | 10-200 mm | Largest bore size |
Typical applications
Typical applications: Assembly and handling systems with low installation heights, machine tools with flat clamping fixtures, conveying technology with guiding tasks in restricted vertical dimensions, pick-and-place machines, and packaging machinery where a low-profile cylinder housing is required.
