Laser fume extractor 80 m³/h at 1,900 Pa, EC blower - ULT LAS 0160.1-MD.11.10.6010
Laser marking and engraving release fume right in the operator's field of view, so it should be captured at source. The LAS 160.1 MD.11 K provides 80 m³/h at 1,900 Pa, up to 190 m³/h and 3,200 Pa vacuum, from a stepless 0.15 kW EC blower. At 49 to 54 dB(A) it stays quiet enough to sit next to the laser, and an optical indicator shows when a filter change is due.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Laser fume is a mixture of aerosols, gases and nanoparticles that does not belong at the workplace. The ULT LAS 160.1 MD.11 K captures it at source and filters it in a multi-stage storage filter system. With a footprint of 405 x 355 x 545 mm the unit stands on castors right next to the laser and runs at a nominal duty point of 80 m³/h at 1,900 Pa.
Benefits
- Nominal duty point 80 m³/h at 1,900 Pa, maximum 190 m³/h and 3,200 Pa vacuum
- EC blower rated 0.15 kW, volume flow set steplessly on the potentiometer
- 49 to 54 dB(A) at 50 to 100 percent air performance thanks to integrated sound insulation
- Main filter module K with H13A combination filter cassette, particle separation rate 99.95 percent
- Exchangeable filter system, every filter removable on its own through the toggle latches
- Two intake ports Ø 50 mm, optional bracket for one Alsident S50 extraction arm
- Protection class IP54, sheet steel housing with RAL 7035 light grey powder coating
- 230 V supply at 50/60 Hz and 1.0 A rated current, no three phase connection needed
Filter build K
- Panel filter F9, filter class ISO ePM1 60 percent to ISO 16890, ULT 4-00302
- Filter mat M5-02, filter class ISO Coarse 85 percent to ISO 16890, ULT 4-00238
- Combination filter cassette H13A with H13 particulate filter to DIN EN 1822 and adsorption filter A with activated carbon bed, ULT 4-00002
- Set of panel filter F9 and filter mat M5, 5 plus 5 pieces, ULT 4-00307
The prefilter stages bind most of the particles and stop the H13 main filter element from clogging early. Changing panel filter and filter mat at shorter intervals extends the service life of the more expensive combination filter cassette.
Applications
Laser cutting, laser marking, laser structuring and laser engraving at single workstations in electronics and metal working. The air volume suits one capture point on a closed or partly open laser enclosure. The filtered clean gas can be returned to the room in recirculation mode, so no heat is lost. Recirculation is not permitted when carcinogenic, mutagenic or reprotoxic substances are extracted.
Compatibility and scope of delivery
Supplied as the ULT 160.1 series extraction and filter unit with a 3.0 m EU mains cable. Capture elements such as DN 50 hoses, bends, hoods or Alsident System 50 extraction arms and the SUB D9 interface belong to the series accessory range and are ordered separately. Filter build SK with an upstream expanded metal prefilter is available as an alternative.
Technical data
| Item number | WL34492 |
|---|---|
| Model | LAS 160.1 MD.11 K |
| Manufacturer | ULT |
| Manufacturer item number | LAS 0160.1-MD.11.10.6010 |
| Order unit | piece |
| Nominal duty point | 80 m³/h at 1,900 Pa |
| Max. volume flow | 190 m³/h |
| Max. vacuum | 3,200 Pa |
| Protection class | IP54 |
| Sound level | 49 to 54 dB(A) at 50 to 100 percent air performance |
| Vacuum generator | EC blower |
| Rated voltage | 230 V |
| Rated frequency | 50/60 Hz |
| Motor rating | 0.15 kW |
| Rated current | 1.0 A |
| Volume flow controller | yes, stepless |
| Particle filter loading indicator | optical |
| SUB D9 interface | optional |
| Dimensions (width x depth x height) | 405 x 355 x 545 mm on castors, 405 x 355 x 492 mm on feet |
| Weight without filters | approx. 21 kg |
| Max. filter weight | approx. 15 kg |
| Intake options | standard 2x Ø 50 mm ports, option 1x bracket with Alsident S50 flange |
| Clean air discharge | 4 adjustable nozzles, both sides at the bottom |
| Housing | sheet steel, RAL 7035 light grey powder coating |
| Mains cable | 3.0 m, EU version CEE 7/7 |
| Weight | 36.000000 |
| Manufacturer Nr. | LAS 0160.1-MD.11.10.6010 |
| HS-Code | 84213925 |
| GPSR manufacturer information | ULT AG Am Göpelteich 1 DE-02708 Löbau www.ult.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Nennweite DN [mm] | 50 |
| Power (W) | 150 W |
| Protection class (IP) | IP54 |
| Filter class | H13 |
| Airflow [m³/h] | 190 |
| Max. vacuum [Pa] | 3200 |
| Sound pressure level [dB(A)] | 54 |
