Grooved plate 30x100 Bosch Rexroth

Bosch Rexroth grooved plates 30 x 100 are wide extruded aluminium profiles used as flat wall and partition elements in modular frame structures. The range covers the M (centre groove) and L/R (left/right groove) variants, both supplied as bars of 5,600 mm (18 pieces per pack). The T-slot nut (3842520922) is the matching connector for the transverse groove. Cut-to-length pricing and pre-cut 1,000 mm lengths are available for both variants.

7 items
1 manufacturer
Net prices plus VAT

Buying guide

How to choose Grooved plate 30x100 Bosch Rexroth

What matters when choosing: properties, comparison and typical applications.

Technical characteristics

⚙ Cross-section 30 x 100 mm - wide flat profile for walls and partitions in the modular system

✓ M and L/R variants - centre groove or side groove for different connection positions

⬡ Standard length 5,600 mm - cut-to-length and 1,000 mm pre-cut available

📦 T-slot nut 3842520922 - matching connector for the transverse groove of the grooved plate

Part number overview

Part number	Type	Length / pack
3842542696	Grooved plate, 30x100 L/R	18 x 5,600 mm
3842542698	Grooved plate, 30x100 M	18 x 5,600 mm
3842993337	Grooved plate, 30x100 L/R	Cut-to-length price
3842993336	Grooved plate, 30x100 M	Cut-to-length price
3842993337-1000	Grooved plate, 30x100 L/R	1,000 mm
3842993336-1000	Grooved plate, 30x100 M	1,000 mm
3842520922	T-slot nut	Connector

Typical applications

Typical applications: Partition walls and visual dividers in assembly and production lines, flat cladding of Bosch Rexroth frame structures, rear panels for workstations, and modular reconfiguration of existing profile systems.

FAQ

Frequently asked questions about Grooved plate 30x100 Bosch Rexroth

What is a Bosch Rexroth grooved plate 30x100 and what industrial applications use these components?

A Bosch Rexroth grooved plate 30x100 is a precision-engineered aluminum extrusion component with standardized T-slot grooves designed for modular assembly systems and mechanical framework construction. These plates serve as structural foundation elements in industrial workstations, assembly lines, machine frames, and ESD-protected work environments across automotive manufacturing, electronics assembly, pharmaceutical production, and precision engineering facilities. The 30x100mm cross-sectional profile provides optimal strength-to-weight ratio for medium-duty applications while maintaining compatibility with standard Bosch Rexroth profile system accessories and fasteners.

What are the key technical selection criteria for choosing between different Bosch Rexroth 30x100 grooved plate variants?

Selection of Bosch Rexroth 30x100 grooved plates depends primarily on length requirements and groove configuration, with available lengths ranging from 100mm to 5600mm for standard variants like the 3842542696 and 3842542698 models. The M-type configuration features centered groove positioning for symmetric loading applications, while L/R variants provide left-right asymmetric groove placement for specialized mounting requirements. Length selection should account for deflection limits under expected loads, with longer spans requiring intermediate support points to maintain structural integrity and prevent excessive bending under operational stresses.

Which industrial standards and certifications apply to Bosch Rexroth 30x100 grooved plate systems?

Bosch Rexroth 30x100 grooved plates conform to DIN EN 755-9 specifications for aluminum structural profiles and ISO 9001 quality management standards ensuring dimensional accuracy and material consistency. The aluminum alloy composition typically meets EN AW-6060 T66 grade requirements providing corrosion resistance and mechanical properties suitable for industrial environments. Profile geometry adheres to Bosch Rexroth proprietary standards ensuring full compatibility with their modular system components including T-nuts, brackets, and connection elements across the complete profile system range.

What are the main differences between the M-type and L/R-type Bosch Rexroth 30x100 grooved plate configurations?

The M-type Bosch Rexroth 30x100 grooved plates feature centrally positioned T-slot grooves providing symmetric mounting capabilities ideal for balanced loading conditions and standard framework applications. L/R-type configurations position the grooves asymmetrically toward the left and right edges, enabling specialized mounting arrangements for applications requiring offset connections or when integrating with existing structures having specific geometric constraints. Both variants maintain identical 30x100mm outer dimensions and wall thickness specifications, with the groove positioning being the primary differentiating factor affecting component selection for specific assembly requirements.

What installation requirements and system compatibility considerations apply to Bosch Rexroth 30x100 grooved plates?

Bosch Rexroth 30x100 grooved plates require T-slot nuts sized 8 or 10 depending on groove specification, with connection torques typically specified between 8-15 Nm for standard aluminum T-nuts to prevent thread stripping. Installation demands proper profile cutting using carbide-tipped saws or specialized profile cutting equipment to maintain dimensional accuracy and prevent burr formation that could interfere with sliding block operation. The plates integrate seamlessly with standard Bosch Rexroth accessories including sliding blocks like model 3842520922, corner brackets, and linear guides while maintaining full compatibility across the complete modular profile system ecosystem.

What are the operating temperature limits and environmental ratings for Bosch Rexroth 30x100 grooved plates?

Bosch Rexroth 30x100 grooved plates operate reliably within temperature ranges from -20°C to +80°C covering standard industrial environmental conditions without dimensional instability or mechanical property degradation. The anodized aluminum surface treatment provides corrosion resistance equivalent to grade AA25 per DIN EN 12373-1 standards, suitable for indoor industrial environments with normal humidity levels. While not carrying specific IP ratings as passive structural components, the profile geometry allows for effective sealing when integrated with appropriate gaskets and covers in applications requiring environmental protection against dust or moisture ingress.

What maintenance schedule and service life expectations apply to Bosch Rexroth 30x100 grooved plate installations?

Bosch Rexroth 30x100 grooved plates require minimal maintenance consisting of periodic cleaning of T-slot grooves to remove accumulated debris and visual inspection for surface corrosion or mechanical damage every 6-12 months depending on environmental conditions. Service life typically exceeds 20 years in standard industrial environments when properly installed and maintained, with the anodized aluminum construction providing excellent long-term dimensional stability and corrosion resistance. Critical inspection points include checking connection hardware torque values annually and examining groove surfaces for wear patterns that might indicate excessive loading or misalignment in the structural system.
