Fastening elements and designation plates

Accessories for valve terminals

Fastening elements and designation plates for Festo valve terminals provide reliable mechanical integration of CPV and CPASC1 series islands into machines and control cabinets. The range includes DIN rail mounting brackets (CPV10/14-VI-BG-NRH-35, CPV10/14-VI-BG-RWL-B), ET200X interface brackets (CPV10/14-VI-BG-ET200X), locking clips (CPV10/14-HS, CPV10/14-HV) and label carriers in sizes 2 through 8 for clear identification of individual valve positions.

⚙ DIN rail mount NRH-35 - 35 mm rail mounting, compatible with CPV10 and CPV14

✓ ET200X-compatible brackets - direct mounting to Siemens ET200X field device, no adapter plate needed

✦ Label carriers BZ-T-2 to BZ-T-8 - writable plastic labels for positions 2-8, two versions (BZ / ST)

⬡ Locking clips HS / HV - mechanical retention against unintentional release of valve modules

🛡 CPASC1-BG-NRH - DIN rail bracket for CPA Sidecontrol series, compact design

Product	Series	Function
CPV10-VI-BG-NRH-35	CPV10	DIN rail mount 35 mm
CPV14-VI-BG-NRH-35	CPV14	DIN rail mount 35 mm
CPV10-VI-BG-ET200X	CPV10	ET200X mounting
CPV14-VI-BG-ET200X	CPV14	ET200X mounting
CPV10-VI-BZ-T-2 to -8	CPV10	Label carrier pos. 2-8
CPV10-VI-ST-T-2 to -8	CPV10	Label carrier, steel version
CPV10/14-HS, HV	CPV10/14	Locking clips
CPASC1-BG-NRH	CPASC1	DIN rail mount

Typical applications: control cabinet mounting of CPV valve islands on DIN rails, integration into ET200X field devices in decentralised automation concepts, labelling of individual valve positions in multi-channel islands for maintenance and commissioning, and mechanical locking of valve modules in applications with vibration or frequent tooling changes.
