Stationary cutting plate 3.2 mm with standard hole pattern for Supercut/LN5 - Iteco 340111

The stationary cutting plate is the wear part and the dimension defining part of the Supercut/LN5: the leads of the loose radial components are inserted into its holes and the guillotine cuts against its edge. The plate thickness of 3.2 mm sets the lead length that remains after the cut. This version carries the standard hole pattern of the LN5 range and covers the 53 x 43 mm cutting area.

Features

• Plate thickness 3.2 mm - it sets the lead length above the plate, the dimension listed in the catalogue as L fix 3.2 mm.
• Standard LN5 hole pattern - matches the layout that Iteco shows for the short machine in the catalogue.
• Cobalt steel - the same material choice as on the original equipment, the cutting edge lasts even when several parts are cut per stroke.
• Spare and exchange part - a worn or re-drilled plate can be replaced without replacing the machine.
• Format 53 x 43 mm - covers the full cutting area of the Supercut/LN5.

Technical data

Applications

Replacement for a worn plate, conversion back of a machine that was temporarily run with a special plate, or a second plate for quick changeover between two component families.

Compatibility and scope of supply

The plate belongs to the Supercut/LN5 cutting machine (Iteco 7915.041) and to its customized version 7915.041SL. For the long LN5L machine the plate 340.211 applies instead. Intermediate plates of up to 3 mm increase the cut length. Supplied as one plate. Made in Italy.
